ウェンデル社の製品取扱
 |
ウェンデル社は電子部品販売、各種国際規格・安全規格の測定・認定業務の電子部品メーカーです。電磁両立性EMC Device、Surge Protection、TVS Diode、Varistorの製品はパソコン、NB、スマートフォン、タブレット、デジカメ、カーナビ、セキュリティシステム、産業用PC、医療用設備、テレコム関係、ネットワーク製品、風力発電システム、LED照明等幅広い分野で利用されてます。 |
ウェンデル社は主にNichTekとBOURNSの電子部品代理店で、在庫量や価格競争力がある、アジアNo.1の販売代理店です。2016年3月に株式会社フューザーと業務提携を致しました。
BOURNSの電子部品在庫情報はこちら
ウェンデル社の主力サービス
幅広いニーズに応えられるEMCと回線保護のプロダクション
|
|
|
 |
 |
 |
 |
TVS Diode
TVS DiodeはタッチパネルコントロールICのレファレンスデザインにも採用されている信頼性、ハイスピードからロースピード、雷サージ保護まで対応しております。
 |
Package： SMD Type ： 0201 / 0402 / 0603 / SMA / SMB / SMC / SOD-123 / SOD-323 / SDO-523 / SOD-882 / SOD-923 SOT-143 / SOT-23 /SOT-236 / SOT-323/ SOT-563 / SOT523 MSOP/ NSOCI/ QSOP / SOIC SC89 / SC70 / DFN1616 / DFN2510 / DFN2626 DIP Type： DO-201 / DO-41 / DO-15 /DO-35 / R-6 Working Peak Reverse Voltage (VRWM)：2.5V~ 440V inimum Breakdown Voltage (VBR)：3V ~ 543 V Peak Pulse Power (W)： up to 15,000W Applications： High Speed Interfaces USB 3.0, HDMI1.3, Display Port, DVI, LVDS, Giga Ethernet, SATA..etc High current surge protect Ethernet POE), RJ45, RJ11 |
TVS DIODE Specifications
PartNumber |
Marking
Code |
BreakdownVoltage
VBR @ IT |
Maximum
Reverse Leakage IR @VRWM (uA) |
Working
Peak Reverse Voltage VRWM (V) |
Maximum
Reverse Surge Current IPP (A) |
Maximum
Clamping Voltage VC @IPP (V) |
|||
Uni |
Bi |
Min
(V) |
Max
(V) |
IT
(mA) |
|||||
| PDC50C110K(B)-SMC | 5PDW |
5BDW |
12.2 |
14.9 |
10 |
800 |
11 |
248.8 |
20.1 |
| PDC50C110J(B)-SMC | 5PDX |
5BDX |
12.2 |
13.5 |
10 |
800 |
11 |
274.7 |
18.2 |
| PDC50C120K(B)-SMC | 5PDY |
5BDY |
13.3 |
16.3 |
10 |
800 |
12 |
227.3 |
22 |
| PDC50C120J(B)-SMC | 5PDZ |
5BDZ |
13.3 |
14.7 |
10 |
800 |
12 |
251.3 |
19.9 |
| PDC50C130K(B)-SMC | 5PED |
5BED |
14.4 |
17.6 |
10 |
500 |
13 |
210.1 |
23.8 |
| PDC50C130J(B)-SMC | 5PEE |
5BEE |
14.4 |
15.9 |
10 |
500 |
13 |
232.6 |
21.5 |
| PDC50C140K(B)-SMC | 5PEF |
5BEF |
15.6 |
19.1 |
10 |
200 |
14 |
193.8 |
25.8 |
| PDC50C140J(B)-SMC | 5PEG |
5BEG |
15.6 |
17.2 |
10 |
200 |
14 |
215.5 |
23.2 |
| PDC50C150K(B)-SMC | 5PEH |
5BEH |
16.7 |
20.4 |
1 |
100 |
15 |
185.9 |
26.9 |
| PDC50C150J(B)-SMC | 5PEK |
5BEK |
16.7 |
18.5 |
1 |
100 |
15 |
204.9 |
24.4 |
| PDC50C160K(B)-SMC | 5PEL |
5BEL |
17.8 |
21.8 |
1 |
50 |
16 |
173.6 |
28.8 |
| PDC50C160J(B)-SMC | 5PEM |
5BEM |
17.8 |
19.7 |
1 |
50 |
16 |
192.3 |
26 |
| PDC50C170K(B)-SMC | 5PEN |
5BEN |
18.9 |
23.1 |
1 |
20 |
17 |
163.9 |
30.5 |
| PDC50C170J(B)-SMC | 5PEP |
5BEP |
18.9 |
20.9 |
1 |
20 |
17 |
181.2 |
27.6 |
| PDC50C180K(B)-SMC | 5PEQ |
5BEQ |
20 |
24.4 |
1 |
10 |
18 |
155.3 |
32.2 |
| PDC50C180J(B)-SMC | 5PER |
5BER |
20 |
22.1 |
1 |
10 |
18 |
171.2 |
29.2 |
| PDC50C190K(B)-SMC | 5PES |
5BES |
21.13 |
25.76 |
1 |
10 |
19 |
147 |
34 |
| PDC50C190J(B)-SMC | 5PET |
5BET |
21.1 |
23.3 |
1 |
10 |
19 |
162.4 |
30.8 |
| PDC50C200K(B)-SMC | 5PEU |
5BEU |
22.2 |
27.1 |
1 |
5 |
20 |
139.7 |
35.8 |
| PDC50C200J(B)-SMC | 5PEV |
5BEV |
22.2 |
24.5 |
1 |
5 |
20 |
154.3 |
32.4 |
| PDC50C220K(B)-SMC | 5PEW |
5BEW |
24.4 |
29.8 |
1 |
5 |
22 |
126.9 |
39.4 |
| PDC50C220J(B)-SMC | 5PEX |
5BEX |
24.4 |
26.9 |
1 |
5 |
22 |
140.8 |
35.5 |
| PDC50C240K(B)-SMC | 5PEY |
5BEY |
26.7 |
32.6 |
1 |
5 |
24 |
116.3 |
43 |
| PDC50C240J(B)-SMC | 5PEZ |
5BEZ |
26.7 |
29.5 |
1 |
5 |
24 |
128.5 |
38.9 |
| PDC50C260K(B)-SMC | 5PFD |
5BFD |
28.9 |
35.3 |
1 |
5 |
26 |
107.3 |
46.6 |
| PDC50C260J(B)-SMC | 5PFE |
5BFE |
28.9 |
31.9 |
1 |
5 |
26 |
118.8 |
42.1 |
| PDC50C280K(B)-SMC | 5PFF |
5BFF |
31.1 |
38 |
1 |
5 |
28 |
100 |
50 |
| PDC50C280J(B)-SMC | 5PFG |
5BFG |
31.1 |
34.4 |
1 |
5 |
28 |
110.1 |
45.4 |
| PDC50C300K(B)-SMC | 5PFH |
5BFH |
33.3 |
40.7 |
1 |
5 |
30 |
93.5 |
53.5 |
| PDC50C300J(B)-SMC | 5PFK |
5BFK |
33.3 |
36.8 |
1 |
5 |
30 |
103.3 |
48.4 |
| PDC50C330K(B)-SMC | 5PFL |
5BFL |
36.7 |
44.9 |
1 |
5 |
33 |
84.7 |
59 |
| PDC50C330J(B)-SMC | 5PFM |
5BFM |
36.7 |
40.6 |
1 |
5 |
33 |
93.8 |
53.3 |
| PDC50C360K(B)-SMC | 5PFN |
5BFN |
40 |
48.9 |
1 |
5 |
36 |
77.8 |
64.3 |
| PDC50C360J(B)-SMC | 5PFP |
5BFP |
40 |
44.2 |
1 |
5 |
36 |
86.1 |
58.1 |
| PDC50C400K(B)-SMC | 5PFQ |
5BFQ |
44.4 |
54.3 |
1 |
5 |
40 |
70 |
71.4 |
| PDC50C400J(B)-SMC | 5PFR |
5BFR |
44.4 |
49.1 |
1 |
5 |
40 |
77.5 |
64.5 |
| PDC50C430K(B)-SMC | 5PFS |
5BFS |
47.8 |
58.4 |
1 |
5 |
43 |
65.2 |
76.7 |
| PDC50C430J(B)-SMC | 5PFT |
5BFT |
47.8 |
52.8 |
1 |
5 |
43 |
72 |
69.4 |
| PDC50C450K(B)-SMC | 5PFU |
5BFU |
50 |
61.1 |
1 |
5 |
45 |
62.3 |
80.3 |
| PDC50C450J(B)-SMC | 5PFV |
5BFV |
50 |
55.3 |
1 |
5 |
45 |
68.8 |
72.7 |
| PDC50C480K(B)-SMC | 5PFW |
5BFW |
53.3 |
65.1 |
1 |
5 |
48 |
58.5 |
85.5 |
| PDC50C480J(B)-SMC | 5PFX |
5BFX |
53.3 |
58.9 |
1 |
5 |
48 |
64.6 |
77.4 |
| PDC50C510K(B)-SMC | 5PFY |
5BFY |
56.7 |
69.3 |
1 |
5 |
51 |
54.9 |
91.1 |
| PDC50C510J(B)-SMC | 5PFZ |
5BFZ |
56.7 |
62.7 |
1 |
5 |
51 |
60.7 |
82.4 |
| PDC50C540K(B)-SMC | 5PGD |
5BGD |
60 |
73.3 |
1 |
5 |
54 |
51.9 |
96.3 |
| PDC50C540J(B)-SMC | 5PGE |
5BGE |
60 |
66.3 |
1 |
5 |
54 |
57.4 |
87.1 |
| PDC50C580K(B)-SMC | 5PGF |
5BGF |
64.4 |
78.7 |
1 |
5 |
58 |
48.5 |
103 |
| PDC50C580J(B)-SMC | 5PGG |
5BGG |
64.4 |
71.2 |
1 |
5 |
58 |
53.4 |
93.6 |
| PDC50C600K(B)-SMC | 5PGH |
5BGH |
66.7 |
81.5 |
1 |
5 |
60 |
46.7 |
107 |
| PDC50C600J(B)-SMC | 5PGK |
5BGK |
66.7 |
73.7 |
1 |
5 |
60 |
51.7 |
96.8 |
| PDC50C640K(B)-SMC | 5PGL |
5BGL |
71.1 |
86.9 |
1 |
5 |
64 |
43.9 |
114 |
| PDC50C640J(B)-SMC | 5PGM |
5BGM |
71.1 |
78.6 |
1 |
5 |
64 |
48.5 |
103 |
| PDC50C700K(B)-SMC | 5PGN |
5BGN |
77.8 |
95.1 |
1 |
5 |
70 |
40 |
125 |
| PDC50C700J(B)-SMC | 5PGP |
5BGP |
77.8 |
86 |
1 |
5 |
70 |
44.2 |
113 |
| PDC50C750K(B)-SMC | 5PGQ |
5BGQ |
83.3 |
102 |
1 |
5 |
75 |
37.3 |
134 |
| PDC50C750J(B)-SMC | 5PGR |
5BGR |
83.3 |
92.1 |
1 |
5 |
75 |
41.3 |
121 |
| PDC50C780K(B)-SMC | 5PGS |
5BGS |
86.7 |
106 |
1 |
5 |
78 |
36 |
139 |
| PDC50C780J(B)-SMC | 5PGT |
5BGT |
86.7 |
95.8 |
1 |
5 |
78 |
39.7 |
126 |
| PDC50C800K(B)-SMC | 5PGA |
5BGA |
88.96 |
108.8 |
1 |
5 |
80 |
34.9 |
143.2 |
| PDC50C800J(B)-SMC | 5PGB |
5BGB |
88.8 |
97.6 |
1 |
5 |
80 |
38.6 |
129.6 |
| PDC50C850K(B)-SMC | 5PGU |
5BGU |
94.4 |
115 |
1 |
5 |
85 |
33.1 |
151 |
| PDC50C850J(B)-SMC | 5PGV |
5BGV |
94.4 |
104 |
1 |
5 |
85 |
36.5 |
137 |
| PDC50C900K(B)-SMC | 5PGW |
5BGW |
100 |
122 |
1 |
5 |
90 |
31.3 |
160 |
| PDC50C900J(B)-SMC | 5PGX |
5BGX |
100 |
111 |
1 |
5 |
90 |
34.2 |
146 |
| PDC50C101K(B)-SMC | 5PGY |
5BGY |
111 |
136 |
1 |
5 |
100 |
27.9 |
179 |
| PDC50C101J(B)-SMC | 5PGZ |
5BGZ |
111 |
123 |
1 |
5 |
100 |
30.9 |
162 |
| PDC50C111K(B)-SMC | 5PHD |
5BHD |
122 |
149 |
1 |
5 |
110 |
25.5 |
196 |
| PDC50C111J(B)-SMC | 5PHE |
5BHE |
122 |
135 |
1 |
5 |
110 |
28.2 |
177 |
| PDC50C121K(B)-SMC | 5PHF |
5BHF |
133 |
163 |
1 |
5 |
120 |
23.4 |
214 |
| PDC50C121J(B)-SMC | 5PHG |
5BHG |
133 |
147 |
1 |
5 |
120 |
25.9 |
193 |
| PDC50C131K(B)-SMC | 5PHH |
5BHH |
144 |
176 |
1 |
5 |
130 |
21.6 |
231 |
| PDC50C131J(B)-SMC | 5PHK |
5BHK |
144 |
159 |
1 |
5 |
130 |
23.9 |
209 |
| PDC50C141K(B)-SMC | 5PHA |
5BHA |
155.7 |
190.4 |
1 |
5 |
140 |
20 |
250.6 |
| PDC50C141J(B)-SMC | 5PHB |
5BHB |
155 |
171 |
1 |
5 |
140 |
22 |
226.8 |
| PDC50C151K(B)-SMC | 5PHL |
5BHL |
167 |
204 |
1 |
5 |
150 |
18.7 |
268 |
| PDC50C151J(B)-SMC | 5PHM |
5BHM |
167 |
185 |
1 |
5 |
150 |
20.6 |
243 |
| PDC50C161K(B)-SMC | 5PHN |
5BHN |
178 |
218 |
1 |
5 |
160 |
17.4 |
287 |
| PDC50C161J(B)-SMC | 5PHP |
5BHP |
178 |
197 |
1 |
5 |
160 |
19.3 |
259 |
| PDC50C171K(B)-SMC | 5PHQ |
5BHQ |
189 |
231 |
1 |
5 |
170 |
16.4 |
304 |
| PDC50C171J(B)-SMC | 5PHR |
5BHR |
189 |
209 |
1 |
5 |
170 |
18.2 |
275 |
| PDC50C181K(B)-SMC | 5PHS |
5BHS |
200.2 |
244.8 |
1 |
5 |
180 |
15.5 |
322.2 |
| PDC50C181J(B)-SMC | 5PHT |
5BHT |
200 |
220 |
1 |
5 |
180 |
17.1 |
291.6 |
| PDC50C191K(B)-SMC | 5PHU |
5BHU |
211.3 |
258.4 |
1 |
5 |
190 |
14.7 |
340.1 |
| PDC50C191J(B)-SMC | 5PHV |
5BHV |
211 |
232 |
1 |
5 |
190 |
16.2 |
307.8 |
| PDC50C201J(B)-SMC | 5PHW |
5BHW |
224 |
247 |
1 |
5 |
200 |
15.4 |
324 |
| PDC50C221J(B)-SMC | 5PHX |
5BHX |
246 |
272 |
1 |
5 |
220 |
14 |
356 |
| PDC50C251J(B)-SMC | 5PHZ |
5BHZ |
279 |
309 |
1 |
5 |
250 |
12.3 |
405 |
| PDC50C301J(B)-SMC | 5PJE |
5BJE |
335 |
371 |
1 |
5 |
300 |
10.3 |
486 |
| PDC50C351J(B)-SMC | 5PJG |
5BJG |
391 |
432 |
1 |
5 |
350 |
8.8 |
567 |
| PDC50C401J(B)-SMC | 5PJK |
5BJK |
447 |
494 |
1 |
5 |
400 |
7.7 |
648 |
| PDC50C441J(B)-SMC | 5PJM |
5BJM |
492 |
543 |
1 |
5 |
440 |
7 |
713 |
1) Suffix K denotes 10% tolerance, suffix J denote 5% tolerance devices.
2) Suffix B after part number to specify Bi-directional devices; U for uni-directional.
3) For Bi-directional devices having VR of 10 volts and under, the IR limit is double.
NichTekのTVS Diode解説書はこちら
Varistor
MOVは雷サージ保護に対応した、SMDタイプのものから、Dipタイプのものまで豊富なラインナップでお客様をサポート。カスタマイズにも対応しております。
 |
SingleType Size(Inch)：0201/0402/0603/0805/1206/1210/1812/2220 DCVoltage：3.3~385V Capacitance：0.3~36500pF HighCurrentType(Single) Size(Inch)：1206/1210/1812/2220 DCVoltage：9~65V SurgeCurrent：500~3000A(8/20waveform) HighVoltageType(Single) Size(Inch)：1206/1210 DCVoltage：9~60VSurgeCurrent：100/150A(10/700waveform) SurgeVoltage：4/6KV |
CHIP MULTILAYER VARISTORS Specifications
Part Number |
WorkingVoltage |
Breakdown
Voltage(*1) |
Clamping
Voltage(*3) |
SurgeCurre
(8/20μs)(*3) |
|
AC |
DC |
V（1mA） |
V |
A |
|
| PVSA321609422T | 6 |
9 |
12(12~20) |
<25 |
500 |
| PVSA321618102T | 14 |
18 |
24(±10%) |
<45 |
500 |
| PVSA321638801T | 30 |
38 |
47(±10%) |
<85 |
500 |
| PVSA321660801T | 48 |
60 |
75(±10%) |
<100 |
500 |
| PVSA322518382T | 14 |
18 |
24(±10%) |
<45 |
1000 |
| PVSA322538202T | 30 |
38 |
47(±10%) |
<85 |
1000 |
| PVSA322560202T | 48 |
60 |
75(±10%) |
<100 |
1000 |
| PVSA453218282T | 14 |
18 |
24(±10%) |
<45 |
2000 |
| PVSA453238142T | 30 |
38 |
47(±10%) |
<85 |
2000 |
| PVSA453260212T | 48 |
60 |
75(±10%) |
<100 |
2000 |
| PVSA575018842T | 14 |
18 |
24(±10%) |
<45 |
3000 |
| PVSA575038492T | 30 |
38 |
47(±10%) |
<85 |
3000 |
| PVSA575045352T | 35 |
45 |
56(±10%) |
<90 |
3000 |
| PVSA575060342T | 48 |
60 |
75(±10%) |
<100 |
3000 |
| PVSA575065202T | 50 |
65 |
82(±10%) |
<135 |
3000 |
*2 The clamping voltage was measured at standard current, 3216(1A), 3225(2.5A), 4532(5A) and 5750(10A).
*3 The surge current was tested at 8/20 μs waveform.
CHIP MULTILAYER VARISTORS Specifications
PartNumber |
Non-linear
Coefficient |
Leakage current |
Capacitance
(*4) |
Response
Time |
Operation
Ambient Temperature |
Storage
Temperat |
|
before
Surge Test |
After
Surge Test |
||||||
α |
μA |
μA |
PF(at 1 KHz) |
Trise |
℃ |
℃ |
|
| PVSA321609422T | 20 |
10 |
80 |
3500 |
<1ns |
-55~+125 |
-55~+150 |
| PVSA321618102T | 20 |
10 |
80 |
2300 |
|||
| PVSA321638801T | 30 |
10 |
80 |
690 |
|||
| PVSA321660801T | 30 |
10 |
80 |
300 |
|||
| PVSA322518382T | 20 |
15 |
80 |
2300 |
|||
| PVSA322538202T | 30 |
10 |
80 |
1550 |
|||
| PVSA322560202T | 30 |
10 |
80 |
930 |
|||
| PVSA453218282T | 20 |
15 |
80 |
4500 |
|||
| PVSA453238142T | 30 |
15 |
80 |
2100 |
|||
| PVSA453260212T | 30 |
15 |
80 |
1650 |
|||
| PVSA575018842T | 20 |
15 |
80 |
5500 |
|||
| PVSA575038492T | 35 |
15 |
80 |
8000 |
|||
| PVSA575045352T | 35 |
15 |
80 |
3500 |
|||
| PVSA575060342T | 40 |
15 |
80 |
2000 |
|||
| PVSA575065202T | 40 |
15 |
80 |
2000 |
|||
*5 The components shall be employed within 1 year, in the nitrogen condition.
NichTekのVaristor解説書はこちら
LAN Transformer
LAN Transformer ラントランスフォーマー（パルストランス）
10/100Mから10GB、シングルからクアッドポート、PoE対応のもの等豊富なラインナップでお客様の需要に対応します。
 |
Type： Pin： 12/16/20/24/36/40/48/72 pin Port： Single / Dual / Quad port Application (RJ45 Port)： Designed to meet IEEE802.3 10/100/1000/10G Base-T PoE (Power over Ethernet) Ethernet Transformers and Chokes |
Surge LAN Transformer
Surge LAN Transformer サージラントランスフォーマー
一般的なLan Transformerと同じピン配列でサージ保護を解決。一般的なLan Transformerを使用した際に使わなければならないTVS Diode、MOV、GDTが必要なくなるので実装費用などを節約、スペースの縮小になり小型化が可能。最近需要が爆発的に伸びているのある台湾、韓国大手ネットワークカメラメーカーが使用、サーバー、屋外用Wifiアクセスポイント、ネットワークスイッチ、スイッチ、ネットワークビデオレコーダー（NVR)などにもおすすめしております。
 |
Designed to meet IEEE802.3 Surge Level：Differential Mode 2KV Common Mord 6KV(IEC-61000-4-5) ESD Level：Air：+/-30KV Contact：+/-24KV Single to multi-port support Data rate： 10/100M & 10/100/1000 Base-T |
PoE Guard
パワーオーバーイーサネットガード
Surge Lan Transformerをご使用のお客様の声から生まれた製品、PoE受電側のデバイスのパワーラインのサージ保護をこれ一つで解決。第2世代になり、4KV、6KV、8KV対応品を用意しております。
 |
High level surge protection device for equipment with PoE interface. Surge Level：Max 150A at 10/700μs waveform(IEC61000-4-5) ESD Level：(IEC61000-4-5) Air：+/-30KV Contact：+/-30KV Compact Size：17x10x1.5mm High forward current,up to 1A Low leakage current Low VF Working voltage：60Vdc |
Surge Pro
サージプロは後付けが可能な10KV雷サージプロテクター。LED電燈（室内、屋外）、工場などの電源保護など幅広い分野でお使いいただけます。
 |
Features： Suitable for Power system equipment for AC intel at 90-305VAC Surge protection Level up to level up to 10kV Compatible surge waveforms 1.2/50μs & 10/700μs Accumulative Surge Level：200KA min Easy installation for indoor and outdoor application. IP67 Application： Power system： Street lighting,digital signage,surveillance, UPS & AVR. |
Thysistor
ThyristorはSMA~SMCのパッケージ、2〜8KVに対応しております。 |
Package：SMA~SMB Repetitive Peak pulse Voltage：2000~6000V(10/700us) |
GDT
Gas Discharge TubesはSMDタイプの小型なものから、Dipタイプの大型のものまで幅広く取り揃えております。
xDSL,T1/E1,RS485/422, LAN/WAN,CATV/CABLE,VOIP,基地局などで使用されています。
 |
Package： SMD Type：3.2x1.6x1.6mm/4.5x3.2x2.7mm/5.0x5.0x4.2mm φ5.0x5.0mm/φ5.0x7.5mm/φ6.0x4.2mm/φ8.0x6.0mm DIP Type：φ5.5x5.0mm/φ5.5x6.0mm/φ6.0x4.2mm/φ8.0x6.0mm φ5.0x7.5mm/φ6.0x8.5mm/φ8.0x10.5mm DC Breakdown Voltage：100V/S：70~120V Impulse Discharge Current@8/20μS：0.5~5/KA |
ウェンデルの見積依頼、在庫確認はこちら
 |
